OPTICAL DESIGN
The S6 10-60x56 ED BR sets a new optical standard for the Benchrest shooters. The design employs two Extra-Low Dispersion (ED) glass elements for an unprecedented shooting experience that provides a 55% improvement* in optical resolution over our award winning and industry standard SIII 10-50x60 LR models. Now you can see those shots on target like never before.
* when compared to the award winning Sightron S3 10-50x60 LR Riflescope
PARALLAX CAM SYSTEM
SIGHTRON redesigned the parallax cam system making it easier to identify when your target is out of parallax. Correction covers 270º of total rotation with full correction from 9 yards to Infinity.
RETICLE DESIGN
The new MOA-BD reticle is purpose built for Benchrest shooters. The new BD (bracket dot) reticle allows you to bracket the target with the use of the zoom. The 2nd focal plane illuminated reticle is uncluttered with just enough information to keep track of where you are when counting clicks. The floating center dot makes it easy to set target placement even at 60x.
MULTICOATING TECHNOLOGY
SIGHTRON’s exclusive Zact-7 Revcoat Plus multi-coating technology applies premium camera grade multi-coatings throughout the optical design for the best possible light transmission, contrast, and clarity for dramatically reduced color fringing, flare, and chromatic aberrations even in the harshest lighting conditions.
EXACTRACK ACCURACY
Never experience reticle drift again. SIGHTRON utilizes their exclusive ExacTrack erector tube system to deliver consistent, reliable, and repeatable adjustments even at the extreme edges of the scope's adjustments. This means 1/8 MOA click values are the same at 20 MOA up as they are at zero. The scope utilizes a highly accurate "boxed" reticle design with 55 MOA of elevation and 40 MOA of windage adjustments in 1/8 MOA increments.
SCOPE CONSTRUCTION
The 34mm tube design is crafted from premium-grade aluminum, weighs 33.6 oz and is tested and shock-rated to 1,000G’s for more than 10k cycles. It can handle the heaviest big-bore Airguns to 50BMG. Of course, it meets IPX7 waterproof standards, is nitrogen charged to prevent fogging of the interior glass elements even when moving from a warm car to sub-zero temps.
LIFETIME PERFORMANCE GUARANTEE
SIGHTRON’s Lifetime Performance Guarantee is backed by a team of skilled technicians in their Custom Shop. If you ever have an issue, they will get your scope working as it should or they will replace it CLICK Here For Warranty Details.
IN THE BOX:
- S6 10-60x56 ED BR w/ MOA-BD Reticle
- Sunshade
- Front and Rear Flip-up lens covers
- Lens Cloth
- (2) Allen Wrenches
SPECS
| Magnification | 10-60x |
| Objective Lens Diameter | 56mm |
| Eye Relief | 3.96 - 3.43 inch / 100.7 - 87.1mm |
| Field of View | 10.96 ft - 1.9 ft @ 100 yards |
| Tube Size | 34mm |
| Turret Style | Tactical + Cover for Windage |
| Zero Stop | Yes |
| Click Value | 1/8 MOA |
| Minutes Per Revolution | 10 MOA |
| Max Elevation Adjustment | 55 MOA |
| Max Windage Adjustment | 40 MOA |
| Parallax Setting | 9 Yards - Infinity |
| Focus Type | Adjustable Side Focus |
| Reticle Type | MOA-BD |
| Focal Plane | Second Focal Plane |
| Illumination | Yes - 11 Intensity Levels |
| Finish / Color | Satin Black |
| Waterproof | Yes - IPX7 Rated |
| Anti-Reflection Tech | Zact-7 Revcoat Plus Multicoatings |
| Shockproof | 1,000G Shock Rating |
| Fog Proof | Yes |
| Length | 16.7 inches |
| Weight | 33.6 ounces |
| Sunshade | Included |
| Item Number | 66012 |
| UPC Code | 793139660121 |
| Model Name | S6 10-60x56 ED BR MOA-BD |
| Country of Origin | Japan |
| Instruction Sheet (PDF) | Not Available |
| Reticle Instructions (PDF) | DOWNLOAD |
