ATN's Obsidian LT core drives this hands free, compact, ergonomic and versatile thermal monocular for the best observation expeirence. In the cover of night, trust ATN to give you sight.
Ergonomic Design
This Compact Thermal Monocular fits in one hand and is easily manipulated, giving the user versatility and easy access to the menu.
Display
The Hi-Res 1280x960 display will provide clear and vivid images of the scene being observed.
HEAD / HELMET MOUNT
This Compact Thermal Monocular can be: Hand held, Helmet or Head mounted for long term comfortable observation of the scene.
Features:
- Lens: 35MM
- Sensor: 320x240 pixels / 12μm
- Frame Rate: 60Hz
- Magnification 4x-9x
- Field of view, degrees: 6.3x4.7
- Core: ATN Obsidian Core LT
- Micro Display: 1280x960 pixels
- IP rating: Weather Resistant
- Battery Type: 1 x CR123A
- Color modes: White Hot / Black Hot
- Battery life (Li-ion) ≈2.5 hr (or Optional Rechargeable Battery with 5 Hrs of runtime)
- Operating Temperature: -20°F to +120°F / -28°C to 48°C
- Dimensions: 5.71"x2.8"x2.01" / 145x71x51 mm
- Weight: 285g
- Human Detection Range: 1510 meters
- Human Recognition Range: 680 meters
- Human Identification Range: 340 meters
Technical Specifications
| Lens | 35 mm |
| Resolution | 320x240, 60 fps, 12 µm |
| Magnification | 4-8x |
| Field of View | 6.3x4.7 |
| Core | ATN Obsidian Core LT |
| Display Resolution | 1280x960 px |
| Eye relief | 25 mm |
| IP rating | Weather resistant |
| Color modes | White Hot, Black Hot |
| Battery type | 1 x CR123A (Li-ion) |
| Battery life (Li-ion) | 2.5 Hrs (or Optional Rechargeable Battery with 5 Hrs of runtime) |
| Charging | USB, type C port is on the Optional Rechargeable Battery |
| Operating Temperature | -20°F to +120°F / -28°C to 48°C |
| Dimensions | 5.71"x2.8"x2.01" / 145x71x51 mm |
| Weight | 342 g |
| Human Detection Range | 1510 |
| Human Recognition Range | 680 |
| Human Identification Range | 340 |
