Application
• Hunting
• Night surveillance
• Patrol / Rescue / Search
• Night photo / video
Features
• Special high-contrast night optics
• 4х and 6х magnification
• Gen. II+, III, XR-5
• Shockproof even with heavy recoil (.375 H&H, .50 cal.)
• Automatic brightness control
• Manual gain control
• Long eye relief
• Precision Mil-Dot reticle with adjustable brightness
• Precision windage/elevation adjustment (10mm/100m or 1/4 МОА)
• Powerful build-in IR illuminator (75 mW)
• Wide range of mounts
• Waterproof
• Light weight
Technical specifications
|
The image intens. tube |
|
|
Type (Gen.) |
II+, III, XR-5 |
|
Photosensitivity, μA/lm |
540 - 1800 |
|
Gain |
25000 - 45000 |
|
Resolution, pl/mm |
45 - 75 |
|
General |
|
|
Magnification, x |
3.7 |
|
Objective lens |
100mmF/1.5 |
|
Field of view, Degree |
9 |
|
Diopter setting, D |
-3, +4 |
|
Eye relief distance, mm |
45...90 |
|
Feed voltage, V |
3 |
|
Power supply |
АА battery - 2 pc |
|
Battery life, hrs |
min. 60 |
|
Operating temperature, °C |
- 40 up to +50 |
|
Relative humidity, % |
98 |
|
Dimensions, mm |
235x98x80 |
|
Weight (w/o mount), kg |
0.9 |
